ManneQuinPRO™ Version 10

IMPORTANT NOTE:

The ManneQuin series of human modeling programs has been the most successful in the world with thousands of users since the original ManneQuin program was introduced in 1990. ManneQuinPRO has now been superseded by HumanCAD and is no longer available for sale.

Universities using ManneQuinPRO in their curriculums are invited to migrate to the new HumanCAD software. However, ManneQuinPRO remains available as a download for a limited time for students and also for customers needing to reinstall the software. The latest update of ManneQuinPRO was released in September 2006.

As of May 1, 2007, we no longer provide support for ManneQuinPRO versions V7.0 and V7.1 and earlier or ManneQuinONSITE.

Upgrade discounts to HumanCAD are available. Email salesinfo@nexgenergo.com for additional information.

A limited quantity of printed ManneQuinPRO V7 user manuals is still available. Please contact us for pricing.

Product Features

• Extensive anthropometric databases of men, women and children including 1988 Natick US Army and NASA-STD-3000
• Five levels of mannequin representation: mannequin, skeleton, HumanForm, robot, and stick figure. Also includes the physically challenged
• Completely articulated body within human ranges of motion
• Sophisticated 2D and 3D drawing/modeling tools
• Three-dimensional biomechanical predictions of the entire body
• Revised NIOSH Lifting Equation
• Frame-by-frame animation capabilities
• Animated walking and simulation
• File Import (3D DXF or 3DS files)
• File Export (3D DXF, 3DS files)
• Field of vision, reach and kick cones
• Print Preview and management
• Multiple concurrent documents and multiple independent views
• Human figures are ergonomically correct for a number of ethnic groups, percentiles and body types
• Simulate lifting, pushing and pulling by adding forces and torque in any direction on any body part
• Animation files can be saved as AVI or MPEG
• Dockable toolbars with tooltips
• Center of Gravity display toggle
• Automatic update of the Ground Reaction when an external force is modified
• Key shortcuts to switch views
• F3 key to enter coordinates when creating objects
• Multiple concurrent views
• OpenGL rendering, with hidden line and shading
• 3D-Orbit feature
• Unlimited undo - Almost all procedures are undoable and the number of undo steps is limited only by available memory
• Ability to enter numerical coordinates when performing a reach function
• Geometric objects can be scaled once created, either interactively or via user defined numerical values
• Dimensioning: Vertical, horizontal, and aligned distances, as well as angles, can be determined either interactively or by user defined numerical values
• Manual control for anthropometry: Individual body segment dimensions can be entered manually to generate a specific anthropometric model
• Semi-auto control for anthropometry: The height and weight values for a model can be entered manually, while the remaining body segments are scaled accordingly
• Digital floor option

• Anthropometric Database
  • 11 populations, including 1988 Natick US Army and NASA-STD 3000
  • Adult male, adult female, child
  • Three somatotypes
  • 2.5, 5, 50, 95, 97.5 percentile mannequins
  • Joint range of motion
  • The anthropometry can be modified once the mannequin is created


• Mannequin Representation
  • 5 levels of detail
  • Includes skeleton and high resolution humanoid (male only)
  • Physically challenged mannequins with wheelchairs, canes, crutches, etc.


• Mannequin Capabilities
  • Articulate body parts within human ranges of motion (range of motion can be customized)
  • Articulation of individual fingers
  • Library of pre-defined mannequin body and hand positions
  • Field of vision cones
  • Reach-envelopes for hands and feet
  • Mannequin reach to selected point


• Viewing
  • Wireframe, shading, and hidden line removal
  • Ability to "see" through selected mannequin eyes
  • Placement of camera, field of view, for any 3D perspective view
  • New "Orbit" feature to freely rotate around the scene


• Drawing/Modeling
  • 2D and 3D drawing and editing tools
  • 3D Primitive solid creation


• Biomechanics
  • NIOSH 1991 lifting calculation
  • Simulate lifting, pushing, pulling by adding forces and torque in any direction, on any body part
  • Automatic calculation of reaction force at feet
  • Biomechanic calculation of reaction joint force and torque due to applied load and body posture
  • Statistical anthropometric information


• Animation
  • Animated walking on specified path
  • Export capability to 3D Studio for enhanced rendering and animation
  • Direct export to an AVI digital video file with any of the available codecs


• Import
  • Import CAD drawings into ManneQuinPRO via 3DS and DXF file format
  • Import Mannequin .MQP files


• Export
  • DXF 3D
  • 3DS (3D Studio)

System Requirements

• IBM compatible PC: Pentium II minimum
• Microsoft Windows 98, Windows Me, Windows NT, Windows 2000 Professional and Windows XP
• Compatible with Windows XP styles
• 128MB memory minimum
• 12MB of available hard disk space
• 3D Hardware accelerated graphics card

ManneQuinPRO FAQ

Click here to view the answers to the most frequently asked questions about ManneQuinPRO.

ManneQuinPRO 30-Day Trial Version Download

Click here to register and download the ManneQuinPRO 30-day trial version.

ManneQuinPRO is a trademark of NexGen Ergonomics Inc.
